Pex-a Pipe Pex-a EVOH Pipe with Size and Price Insulation Underfloor Heat
External coating of oxygen barrier PEX tubing effectively prevents diffusion of oxygen molecules into the water through walls of the pipe. This feature prevents corrosion of cast iron components in the system (circulator pumps, air purgers, fill valves, boiler heating elements, etc.) and allows using it in hot water hydronic heating applications, including baseboard/radiator heating, fan coils, and radiant floor heating applications.
- Overview
- Parameter
- FAQ
- Recommended Products
1.External coating of oxygen barrier PEX tubing effectively prevents diffusion of oxygen molecules into the water through walls of the pipe. This feature prevents corrosion of cast iron components in the system (circulator pumps, air purgers, fill valves, boiler heating elements, etc.) and allows using it in hot water hydronic heating applications, including baseboard/radiator heating, fan coils, and radiant floor heating applications.
2.The producing of PEX-a pipe is strictly comply with ISO 15875
3.High flexibility ,be easy bent and curved at low temperature
4.Temperature resistance: usable range -20ºC-95ºC
5.Good thermal memory
6.Pressure Resistance: up to the highest pressure standard of China floor heating system
|
OD (mm) |
Thickness (mm) |
Tolerance (mm) |
OD (mm) |
Thickness (mm) |
Tolerance(mm) |
OD (mm) |
Thickness(mm) |
Tolerance(mm) |
|
16 |
1.8 |
0.3 |
20 |
1.9 |
0.3 |
25 |
2.3 |
0.3 |
|
16 |
2.0 |
0.3 |
20 |
2.0 |
0.3 |
25 |
2.8 |
0.3 |
|
16 |
2.2 |
0.3 |
20 |
2.3 |
0.3 |
25 |
3.5 |
0.3 |
|
20 |
2.8 |
0.3 |
||||||
|
OD (mm) |
Thickness (mm) |
Tolerance (mm) |
|
|||||
|
32 |
2.9 |
0.3 |
||||||
|
32 |
3.6 |
0.3 |
||||||
|
32 |
4.4 |
0.3 |
||||||
The Anti-oxygen layer can effectively prevent oxygen from entering the piping system, it inhibits bacterial and algal reproduction,prevent fouling,guarantee the water quality freshly and cleanly.
The oxygen transmission rate<0.1g(d:m)3,it can prevent the oxygen from seeping into the piping system,and prevent the water pollution problems caused by corrosion and rust of metal parts in HAVC system.Therefore,it extend the service life of the metal parts such as manifold and boiler in the heating system.
1.Made of LG HDPE materials -XL1800 Or SL188, Cross linker and peroxide are both imported, PEX-a Pipe high quality
2.Extruders are all imported from Korea with automatic feed materials system. Which is make mixing materials safely.
3.PEX-a pipe is can bear from - 20ºC to +95ºC, heat conductivity coefficient is 0.4W/m.k. Smooth inner and outer surface. Low fluid resistance and fluid noise
4.The high degree of cross-linking, east of installation , resistance to acidic water.
5.Forma three-dimensional network, PEX-a is the most flexible of all PEX types ( PEx-b & PEX-c)
6.Excellent Antiseptic performance and anti -toroidal stress at break in low temperature
7.No Toxic ,no taste no corrosion, bacteria resistant, complied with the GB/T18992.2-2003 stanard.
8.24 hours Quality Control online. Each coil testing with pressure. Making the pipe with 50 years lifetime.
1.Floor panel heating/cooling system
2.Plumbing system
3.Solar Energy
4.HVAC system
5.Radiator syste
